T-SQL Puzzler

UPDATE: I have included an alternate solution from one of my readers!

I have presented on T-SQL Window Functions at least 30 times over the past five years. I love the comments I get after the presentations. Without fail, at least one person will tell me how the session helped them figure out the solution to a problem they have been struggling with for months. Sometimes, a person will ask my advice about a particular query. At least for me, it’s difficult to just come up with a solution in a couple of minutes while I am trying to clear the area for the next presenter. At Cleveland SQL Saturday, a gentleman presented me with a puzzle that I really enjoyed solving. He gave me permission to share it with you.

The problem involves a call center. Each employee answers calls until time for the next employee to go on duty. Sometimes, an employee will come back later in the day. For example, employee 1 has two shifts on the first day.

Here is a script to create a table and populate it with some sample data:

CREATE TABLE calllist(empID int, CallDate date, CallTime time);

INSERT INTO calllist
VALUES (1,’1/1/2017′,’9:15′),(1,’1/1/2017′,’9:18′),(1,’1/1/2017′,’9:20′),(1,’1/1/2017′,’12:00′),(2,’1/1/2017′,’13:00′),(2,’1/1/2017′,’13:15′),(2,’1/1/2017′,’13:18′),(2,’1/1/2017′,’13:20′),(1,’1/1/2017′,’15:00′),(1,’1/1/2017′,’15:15′),(3,’1/1/2017′,’18:00′),(3,’1/1/2017′,’18:15′),(3,’1/1/2017′,’18:30′),(3,’1/2/2017′,’9:15′),(3,’1/2/2017′,’9:18′),(3,’1/2/2017′,’9:20′),(3,’1/2/2017′,’12:00′),(1,’1/2/2017′,’13:00′),(1,’1/2/2017′,’13:15′),(1,’1/2/2017′,’13:18′),(2,’1/2/2017′,’13:20′),(1,’1/2/2017′,’15:00′),(1,’1/2/2017′,’15:15′),(3,’1/2/2017′,’17:00′),(3,’1/2/2017′,’17:15′),(3,’1/2/2017′,’19:30′);

The required outcome will display each employee shift along with the first and last call:

ntsqp1

To come up with a solution, I first thought about how to solve it with a traditional cursor. I won’t provide a cursor solution here, but it would involve looping through the rows in order and finding the first and last employee rows. When the last EmpID doesn’t match the next EmpID, then the previous row is the last call for the previous EmpID and the current row is the first call for the next EmpID.

NOTE: The solution to this problem assumes that there are at least two calls per shift.

In 2012, four T-SQL window functions became available that let you look at expressions from different rows: LAG, LEAD, FIRST_VALUE, and LAST_VALUE. For this puzzle, LAG and LEAD seemed to be the answer.  In this case, I used the optional default parameter to replace any NULLs with -1.

SELECT *,
    LAG(empID,1,-1) OVER(PARTITION BY CallDate ORDER BY calltime)
    AS   PrevEmpID,
    LEAD(empID,1,-1) OVER(PARTITION BY CallDate ORDER BY calltime)  AS NextEmpID
FROM calllist
ORDER BY CallDate, CallTime;

Here are the partial results:

ntsqp2

The next step is to compare the current EmpID with the previous and next values. When they don’t match, then the row is either the first call or the last call for that employee. To solve this in a step-by-step manner, the previous query is moved to a common table expression (CTE).

WITH CTE1 AS (
    SELECT *,
       Lag(empID,1,-1) OVER(PARTITION BY CallDate ORDER BY calltime) AS
         PrevEmpID,
    LEAD(empID,1,-1) OVER(PARTITION BY CallDate ORDER BY calltime)  AS NextEmpID
FROM calllist
)
SELECT empID, CallDate, CallTime,
    CASE WHEN EmpID  PrevEmpID THEN 1 END AS FirstCall,
    CASE WHEN EmpID  NextEmpID THEN 1 END AS LastCall
FROM CTE1;

ntsqp3

The next step is to eliminate the rows that are not a first or last call. Once again, the previous outer query is added to a CTE.

WITH CTE1 AS (
    SELECT *,
      LAG(empID,1,-1) OVER(PARTITION BY CallDate ORDER BY calltime) AS
         PrevEmpID,
      LEAD(empID,1,-1) OVER(PARTITION BY CallDate ORDER BY calltime) AS
         NextEmpID
FROM calllist
),
CTE2 AS (
    SELECT empID, CallDate, CallTime,
       CASE WHEN EmpID  PrevEmpID THEN 1 END AS FirstCall,
       CASE WHEN EmpID  NextEmpID THEN 1 END AS LastCall
FROM CTE1)
SELECT empID, CallDate, CallTime, FirstCall, LastCall
FROM CTE2
WHERE FirstCall IS NOT NULL OR LastCall IS NOT NULL;

ntsqp4

Now we can take advantage of the LEAD function again to grab the CallTime from the following row. Again, the previous outer query is a new CTE level.

WITH CTE1 AS (
    SELECT *,
       LAG(empID,1,-1) OVER(PARTITION BY CallDate ORDER BY calltime) AS
         PrevEmpID,
       LEAD(empID,1,-1) OVER(PARTITION BY CallDate ORDER BY calltime) AS
         NextEmpID
FROM calllist
),
CTE2 AS (
    SELECT empID, CallDate, CallTime,
       CASE WHEN EmpID  PrevEmpID THEN 1 END AS FirstCall,
       CASE WHEN EmpID  NextEmpID THEN 1 END AS LastCall
FROM CTE1),
CTE3 AS (
    SELECT empID, CallDate, CallTime, FirstCall, LastCall
    FROM CTE2
    WHERE FirstCall IS NOT NULL OR LastCall IS NOT NULL)
SELECT EmpID, CallDate, CallTime, FirstCall,
    LEAD(CallTime) OVER(PARTITION BY CallDate ORDER BY CallTime) AS NextCallTime
FROM CTE3;

ntsqp5

The final step is to eliminate the rows where FirstCall is null.

WITH CTE1 AS (
    SELECT *,
       LAG(empID,1,-1) OVER(PARTITION BY CallDate ORDER BY calltime) AS
         PrevEmpID,
       LEAD(empID,1,-1) OVER(PARTITION BY CallDate ORDER BY calltime) AS
         NextEmpID
FROM calllist
),
CTE2 AS (
    SELECT empID, CallDate, CallTime,
        CASE WHEN EmpID  PrevEmpID THEN 1 END AS FirstCall,
        CASE WHEN EmpID  NextEmpID THEN 1 END AS LastCall
FROM CTE1),
CTE3 AS (
    SELECT empID, CallDate, CallTime, FirstCall, LastCall
    FROM CTE2
    WHERE FirstCall IS NOT NULL OR LastCall IS NOT NULL),
CTE4 AS (
    SELECT EmpID, CallDate, CallTime, FirstCall,
    LEAD(CallTime) OVER(PARTITION BY CallDate ORDER BY CallTime) AS NextCallTime
FROM CTE3)
SELECT EmpID, CallDate, CallTime AS FirstCallTime, NextCallTime AS LastCallTime
FROM CTE4
WHERE FirstCall IS NOT NULL;

Here is the final result:

ntsp6

It’s possible to eliminate one CTE level by using LEAD to find the next call time for every row in step 1. Maybe there is even a better way to solve this query. Add a comment if you have figured out another solution.

To learn more about T-SQL window functions, check out my book or Pluralsight course!

After posting this, one of my readers, Uri Dimant, contacted me about another solution. His solution is a mix of CTE and nested subquery, so I have rearranged it to just use CTEs. There is no difference really, except that I think it is easier to understand with CTEs. This solution is very similar to the Islands technique:

WITH cte1 AS (
	SELECT *,ROW_NUMBER () OVER (ORDER BY CallDate,CallTime) ordinal
	FROM calllist ),
cte2 AS (
	SELECT *, ordinal - ROW_NUMBER() OVER(PARTITION BY empid ORDER BY ordinal) AS grp
	FROM cte1 )
SELECT empid,CallDate,MIN(CallTime) FirstCallTime,MAX(CallTime) LastCallTime
FROM cte2
GROUP BY CallDate,empid,grp ORDER BY MIN(ordinal) ;

This solution uses the difference in two ROW_NUMBERS to create groupings. Once you have the groups, you can just get the MIN and MAX. This solution is very straightforward. At least for me, I understand the solution that I came up with, but both are valid.

Posted in T-SQL, T-SQL Window Functions | 2 Comments

New Pluralsight Course on Mobile Reports is Live!

When I wrote my book on SSRS 2016 last year, I devoted one chapter to Mobile Reports. That chapter was just an overview and didn’t really drill down to most of the properties. I then decided that Mobile Reports would be a great topic for a Pluralsight course.

I didn’t realize that many of the controls would be fairly complex to configure, so I spent much more time on them than I had originally planned. The gauges are simple to configure, but the charts are more challenging. In my opinion, this is the opposite experience found in traditional SSRS reports.

If you have a Pluralsight subscription, be sure to take a look at my new course. If you would like a 30 day trial subscription, please fill out the Contact Me form on this site.

I am thrilled that my course is finally done, and I hope you enjoy watching it!



Posted in SSRS | Leave a comment

Keeping KPI Reports up to Date

Last time, I talked about a very useful new feature of SSRS, KPI reports. These reports stand alone in the web portal, and they also run in the mobile Power BI apps along with Mobile Reports. To view the reports, you just launch the web portal and navigate to the folder where they are published. You could also add them to your Favorites folder to save some time.

Because these reports automatically show the data, the reports show cached data only. Imagine if hundreds or even thousands of report users brought the web portal page up each day causing the KPI reports to hit the database even when the report user was not interested in seeing the KPI reports at that time. That is why Microsoft decided to use cached data only in these reports.

When the data changes, the KPI report will continue to show the same information unless you configure a cache refresh plan on the dataset. Follow these instructions so that the KPI data will refresh on a scheduled basis.

1.       Credentials must be saved in the data source for this to work, so configure that first if needed.

2.       Start up SQL Server Agent on the SQL Server instance hosting the Reporting Services databases if it is not running.

3.       Navigate to the dataset properties and click Caching.

1

4.       Select “Cache copies of this dataset and use them when available.”

2

5.       Under “Cache refresh plans” click Apply.

3

6.       Once you click Apply, you will see a link “Manage refresh plans”. Click it.

4

7.       Click “+ New cache refresh plan.”

5

8.       Fill in the schedule properties and click “Create cache refresh plan.” Be sure to consider how often the data is updated when creating the schedule.

6

You have now created a cache plan for the dataset so that the KPI data will stay up to date. Dataset caching is very similar to SSRS subscriptions. A SQL Agent job will be used to update the dataset. Just because the job runs successfully does not mean that the dataset was successfully refreshed. View the caching page to see the actual status. 7

There is one other interesting thing to know about KPIs and dataset caching. It’s possible to use a parameterized dataset with KPIs. In that case, a default parameter must be entered in the cache refresh plan properties.

8

In the KPI dataset properties, you will also supply a parameter value. It must be the same value as was entered into the cache refresh property.

9

IMPORTANT: When I first tried using a parameterized dataset with a KPI report, running the refresh job didn’t update the KPI. Microsoft corrected this recently with the release of the first cumulative update after Service Pack 1. Be sure to use apply this CU or avoid using a parameterized dataset with a KPI.

I saw several presentations and blog posts about the new KPIs but not many mention that dataset caching must be set up. This is important information to know if you plan to implement this feature at your company.

Posted in SSRS | 1 Comment
